Lift Arm and ROPS/FOPS 16. Remove 6 cable ties (G, Fig. 198). 17. Loosen hose clamp (K), and disconnect heater hose (L) from heater control valve (M). K
O
G L
M M Fig. 199 – Disconnect Heater Control Valve Solenoid
21. Disconnect wiring connectors (P and Q, Fig. 200). NOTE: Label all wires and wiring connectors before disconnecting to ensure correct installation. G N P Fig. 198 – Disconnect Heater Hoses
18. Remove cable ties (G).
R
19. Pull heater return hose (N) from engine compartment.
Q T
20. Disconnect wiring connector (O, Fig. 199) from the heater control valve (M) solenoid.
S
NOTE: Label all wiring connectors before disconnecting to ensure correct installation.
Fig. 200 – Disconnect Wiring Connectors and Ground Strap
22. Remove nut (R), and remove ground strap (S) and ground wire (T).
