Lift Arm and ROPS/FOPS 3. Shut off the engine. With the operator staying in the operator’s position a second person must support the raised lift arm using a suitable overhead crane/hoist. Once the lift arm is properly supported, the operator can exit the machine. 4. With the tilt cylinders fully extended:
5. Start the machine and tilt/rotate the attachment hitch back far enough to install screws into brackets (T, Fig. 172) on both sides of the attachment hitch. Stop the machine. 6. Install 3/4” x 2” screws (C) into both brackets (T). Loosely tighten screws (C) by hand to allow for further adjustment.
• If both tilt stop screws (A, Fig. 173) just touch lift arm stops (V), skip to step 15. • If both tilt stop screws (A) DO NOT just touch lift arm stops (V), proceed to the next step in this procedure.
T
A C
Fig. 172 – Temporary Tilt Stop Adjustment Screws V
Fig. 171 – Tilt Stop Adjustment
IMPORTANT: Two special tilt stop adjustment screws [Manitou part # 50302454] are required to perform the rest of this procedure.
7. Start the machine and tilt/rotate the attachment hitch forward until the tilt cylinders are fully extended. Stop the machine. 8. Adjust both screws (C, Fig. 173) so they just touch lift arm stops (V) when the tilt cylinders are fully extended.
C
V T
Fig. 173 – Tilt Stop Adjustment
