Golf 2015 ➤ , Golf Variant 2015 ➤ Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015 – Remove the bolts -1 through 6-. AG. Volkswagen AG d agen oes ksw not l o V gu by ara d e nte is r o eo h ut ra a c s s
– Remove sealing flange.
♦ Be sure to check the expiration date of the silicone sealant.
rrectness of i t to the co nf o r m spec atio h re n in wit
♦ The sealing flange must be installed within 5 minutes after ap‐
ility ab y li an pt ce
Note
plication of Silicone Sealant.
♦ To prevent contamination of the lubricating system with seal‐
ant residue, place a clean cloth over the open components of the oil pan. CAUTION
Risk of injuring the eyes from sealant residue. – Wear protective eyewear. – Remove remaining sealant on the cylinder head with a flat blade scraper or with a rotating plastic brush. – Sealing surfaces must be free of oil and grease.
agen lksw Vo by
AG.
Prote cted by c o p yri gh t. C op yi
– Apply silicone sealant as illustrated to the clean sealing sur‐ face of the sealing flange. ♦ Sealant bead thickness: 2 to 3 mm. Note ♦ The sealing flange must be installed within five minutes after
application of silicon sealant.
♦ The sealant bead may not be thicker than specified, otherwise
excess sealant could enter the oil pan and clog the oil intake tube.
60
Rep. Gr.13 - Crankshaft, Cylinder Block
ht rig py Co t.
– Cut the tube nozzle at the front marking (nozzle diameter: ap‐ proximately 2 mm).
thi sd o cu m en
es, in part or in w l purpos hole ercia , is n m m ot p o c erm or e t a itte iv r du rp o nl f e ng
Installing
