3.7 Sensor Wheel, Removing and Installing

Golf 2015 ➤ , Golf Variant 2015 ➤ Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015

– Remove the bolts -1 through 6-. Protected by copyright . Co ying for pivate or co merci al p r po s e , i n p a r t r o r in w ho le, is not permitted unless authorised by Volkswagen AG. Volkswagen AG does notguarantee or accept any liabilit y wi th res pect t o t h e c o r r e c t n e ss o f in format ion in this document. Copyright by Volkswagen AG. – Remove sealing flange. Installing Note ♦ Be sure to check the expiration date of the silicone sealant. ♦ The sealing flange must be installed within 5 minutes after ap‐plication of Silicone Sealant. ♦ To prevent contamination of the lubricating system with seal‐ant residue, place a clean cloth over the open components of the oil pan. s CAUTION u Risk of injuring the eyes from sealant residue. – Wear protective eyewear. m – Remove remaining sealant on the cylinder head with a flat blade scraper or with a rotating plastic brush. – Sealing surfaces must be free of oil and grease. p – Cut the tube nozzle at the front marking (nozzle diameter: ap‐proximately 2 mm). – Apply silicone sealant as illustrated to the clean sealing sur‐face of the sealing flange. ♦ Sealant bead thickness: 2 to 3 mm. Note

♦ The sealing flange must be installed within five minutes after application of silicon sealant. ♦ The sealant bead may not be thicker than specified, otherwise excess sealant could enter the oil pan and clog the oil intake tube.
