o1.2 Exhaust Pipes/Mufflers, Separating

Golf 2015 ➤ , Golf Variant 2015 ➤ Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015

The Oxygen Sensor 1 before Catalytic Converter - GX10- is com‐posed of: ♦ Heated Oxygen Sensor - G39♦ Oxygen Sensor Heater - Z19Removing – Disconnect the connector -2- of the Oxygen Sensor 1 before

Catalytic Converter - GX10- .

– Remove the Oxygen Sensor 1 before Catalytic Converter -

GX10- -1- using a tool from the Ring Wrench 7-Piece Set 3337- .

Installing Note the following when installing:

Note

♦ Coat new oxygen sensors with an assembly paste. This paste must not come into contact with oxygen sensor slots. Protected by copyright . Copying for pivate or co merci al pur po s e s , i n p a r t r o r in w ho le, is not permitted unless authorised by Volkswagen AG. Volkswagen AG does notguarantee or accept any liabilit y wi th res pect t o t h e c o r r e c t n e ss o f in format ion in this document. Copyright by Volkswagen AG. ♦ For a used oxygen sensor, only coat threads with hot bolt paste. This paste must not come into contact with oxygen sensor slots. Hot bolt paste. Refer to the Parts Catalog. ♦ The oxygen sensor wire must always be attached at the same location when installing. Do not the electrical wire connection come in contact with the exhaust pipe. Tightening Specifications ♦ Refer to ⇒ “8.1 Overview - Heated Oxygen Sensor”, page 333 . 8.3 Oxygen Sensor 1 after Catalytic Con‐verter - GX7- , Removing and Installing m The Oxygen Sensor 1 after Catalytic Converter - GX7- is com‐posed of: ♦ Oxygen Sensor after Three Way Catalytic Converter - G130♦ Heater For Oxygen Sensor 2 after Catalytic Converter - Z30Special tools and workshop equipment required ♦ Ring Wrench 7-Piece Set - 3337-
