Cylinder Block, Transmission Side
⇒ “2.1 Overview - Cylinder Block, Transmission Side”, page 57 ⇒ “2.2 Flywheel, Removing and Installing”, page 58 ⇒ “2.3 Sealing Flange, Removing and Installing, Transmission Side”, page 59
Overview - Cylinder Block, Transmission Side
es, in part or in w l purpos hole ercia , is n m m ot p o c erm or e t a itte iv r du rp o nl f e ng
thi sd o cu m en
agen lksw Vo by
AG.
Prote cted by
c o p yri gh t . C op yi
3 - Sealing Flange, Transmis‐ sion Side ❑ With seal ❑ Replace after removing ❑ Removing and instal‐ ling. Refer to ⇒ “2.3 Sealing Flange, Removing and Instal‐ ling, Transmission Side”, page 59 . ❑ Do not oil or grease the sealing lip of seal ❑ Wipe off any oil on the crankshaft bearing pin with a clean cloth before installing. ❑ Guide sleeve may only be removed after the sealing flange has been slid onto the crankshaft pin.
rrectness of i t to the co nf o r m spec atio h re n in wit
2 - Alignment Sleeve
n AG. Volkswagen AG do es n wage s k l ot g o yV ua b d ran ir se tee o h t or u ac a ss
ility ab y li an pt ce
1 - Flywheel ❑ Removing and instal‐ ling. Refer to ⇒ “2.2 Flywheel, Re‐ moving and Installing”, page 58 . ❑ It is possible to install in one position only, the holes are offset.
ht rig py Co t.
2.1
4 - Cylinder Block 5 - Bolt ❑ Tightening specification and sequence. Refer to ⇒ “2.3 Sealing Flange, Removing and Installing, Transmission Side”, page 59 . 6 - Intermediate Plate ❑ Illustration does not correspond to version in vehicle. ❑ Must be located on dowel sleeves ❑ Be careful not to damage or bend when installing ❑ Is hooked in at sealing flange. Refer to ⇒ Fig. ““Installing Intermediate Plate”“ , page 58 7 - Alignment Sleeve 8 - Bolt ❑ 60 Nm + 90° turn ❑ Replace after removing 2. Cylinder Block, Transmission Side
57
