Golf 2015 ➤ , Golf Variant 2015 ➤ Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015
1.1.3
Overview - Muffler, Golf Wagon
1 - Retaining Loop ❑ Replace if damaged 2 - Bolt ❑ 20 Nm 3 - Mount ❑ Replace if damaged
5 - Retaining Loop ❑ Replace if damaged
7 - Bolt ❑ 20 Nm
r fo ng
6 - Mount ❑ Replace if damaged
rrectne s s o f i t to the co n form spec atio h re n wit i n thi sd o c um en
urposes, in part or in wh ole, cial p is n mer m ot p o c erm or e t a itte v i r d p
un le
ility ab y li an pt ce
4 - Center Muffler ❑ Original equipment as one unit with rear muf‐ fler. For repairs, replace each separately n AG. Volkswagen AG do es n wage s k l ot g o ❑ Removing and instal‐ yV ua b d ran ling. Refer to e tee ris o ⇒ “1.3 Muffler, Remov‐ h t or u ac a ing and Installing”, page ss 343 . ❑ Separating the exhaust pipes/mufflers. Refer to ⇒ “1.2 Exhaust Pipes/ Mufflers, Separating”, page 342 . ❑ Exhaust System, Instal‐ ling without Tension. Refer to ⇒ “1.4 Exhaust System, Installing without Ten‐ sion”, page 345 .
8 - Rear Muffler ❑ Original equipment as one unit with center muffler. For repairs, replace each separately ❑ Removing and installing. Refer to ⇒ “1.3 Muffler, Removing and Installing”, page 343 . ❑ Separating the exhaust pipes/mufflers. Refer to ⇒ “1.2 Exhaust Pipes/Mufflers, Separating”, page 342 . ❑ Exhaust System, Installing without Tension. Refer to ⇒ “1.4 Exhaust System, Installing without Tension”, page 345 . ht rig py Co t.
agen lksw Vo by
AG.
Prote cted by c o py rig ht . C op yi
9 - Rear Clamping Sleeve ❑ Before tightening, align exhaust system free of tension. Refer to ⇒ “1.4 Exhaust System, Installing without Tension”, page 345 . ❑ Installed position. Refer to ⇒ “1.6 Clamping Sleeve Installation Position”, page 347 ❑ Tighten threaded connections evenly. 10 - Nut ❑ 30 Nm
1. Exhaust Pipes/Mufflers
341
