Golf 2015 ➤ , Golf Variant 2015 ➤ Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015 3 - Bolt ❑ 20 Nm 4 - Bracket 5 - Retaining Loop ❑ Replace if damaged
ility ab y li an pt ce
es, in part or in w l purpos hole ercia , is n m ot p om c r erm o e t a itte riv du p or nl f e g n
6
AG. Volkswagen AG d agen oes ksw not l o V gu - Rear Muffler y b ara d nte se i r ❑ Original equipment as one unit with rear muffler. For repairs, replace each separately o eo h t u ra a c s ❑ Removing and installing. Refer to ⇒ “1.3 Muffler, Removing and Installing”, page 343 . s
❑ Separating point. Refer to ⇒ “1.2 Exhaust Pipes/Mufflers, Separating”, page 342 . ❑ Exhaust System, Installing without Tension. Refer to ⇒ “1.4 Exhaust System, Installing without Tension”, page 345 . rrectness of i t to the co nform spec at i h re o n wit in t his
7 - Rear Clamping Sleeve ❑ Before tightening, align exhaust system free of tension. Refer to ⇒ “1.4 Exhaust System, Installing without Tension”, page 345 . ❑ Installed position. Refer to ⇒ Fig. ““Installation Position for Rear Clamping Sleeve”“ , page 347 ❑ Tighten threaded connections evenly. ❑ Tightening specification. Refer to ⇒ Fig. ““Tightening Specification of Clamping Sleeve”“ , page 347 .
do c um en
1. Exhaust Pipes/Mufflers
339
