Golf 2015 ➤ , Golf Variant 2015 ➤ Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015 Removing – Open the retainer in direction of -arrow- and remove the cover -2-. – Remove the engine cover. Refer to ⇒ “3.1 Engine Cover, Removing and Installing”, page 38 . – Remove the bolts -1 and 3-.
– Free up the coolant hose -2-. t gu ara nte eo ra c
yV db ise r tho au s s
rrectness of i t to the co nform spec a t i h re o n in wit thi s
es, in part or in w l purpos hole ercia , is n m ot com
pe rm itte d
ility ab y li an pt ce
un le
– Open the retaining tabs in direction of -arrows-, remove swagen AG AG. Volkthe does agen w upper air duct -1-. s k no ol
– Remove the left and right bolts -arrow-. – Unclip and remove the lower section -1- of the air duct. – Remove the noise insulation. Refer to ⇒ Body Exterior; Rep. Gr. 66 ; Noise Insulation; Overview - Noise Insulation .
– Loosen the hose clamp -2-, remove the air duct hose from the charge air cooler.
