– Remove the nuts -A- from the intake manifold and remove the bolts -arrows- using the Torx Socket - T30 - T10347- .
– Pull the intake manifold slightly away from the cylinder head and remove the bolts -arrows- for the bracket -A-.
Prote cted by
Installing – If the connections on the high pressure pump were loosened, replace the connections. – Position the intake manifold on the cylinder head and tighten the connector bracket -A-.
308
Rep. Gr.24 - Multiport Fuel Injection
AG.
Cover the intake channels with a clean cloth.
agen lksw Vo by
c o p yri gh t. C op yi
Note
ht rig py Co t.
r fo ng
– Remove the intake manifold from the cylinder head.
rrectne s s o f i t to the co n form spec atio h re n wit i n thi sd o c um en
urposes, in part or in wh ole, cial p is n mer m ot p o c erm or e t a itte v i r d p
ility ab y li an pt ce
un le
– Disconnect the connector -1- from the Intake Manifold Runner Position Sensor - G336- .
