Golf 2015 ➤ , Golf Variant 2015 ➤ Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015 Note ♦ Fill the ultrasonic device up to the upper edge of the holes with
cleaner (see the magnified area of the illustration).
♦ Observe the safety precautions and the operating instructions
for the ultrasonic device.
Cleaning – Remove the fuel injectors. Refer to ⇒ “2.2 Fuel Injectors, Removing and Installing”, page 285 . – The ultrasonic device must be filled with cleaning fluid. – Install the combustion chamber fuel injectors -1- all the way into the Mounting Plate for Injection Modules - VAS6418/1-2-. – Dip the combustion chamber fuel injectors into the cleaner with the Mounting Plate for Injection Modules - VAS6418/1- . – Set the temperature control -4- to 50 °C (122 °F). – Set the time control -5- to 30 minutes. – Turn on the ultrasonic device -3-. Note . Volkswagen AG gen AG does not gu ara nte eo ra c
The time begins counting down once the cleaning temperature Volkswa by reaches 50 degrees. ed un le
pe rm itte d
AG.
Prote cted by
Rep. Gr.24 - Multiport Fuel Injection
agen lksw Vo by
c o p yri gh t . C op yi
292
do c um en
r te o iva r rp fo g n
rrectness of i t to the co nform spec a t i h re o n in wit thi s
es, in part or in w l purpos hole ercia , is n m ot com
– Install the combustion chamber fuel injectors. Refer to ⇒ “2.2 Fuel Injectors, Removing and Installing”, page 285 .
ht rig py Co t.
ter cleaning each combustion chamber fuel injector. Refer to ⇒ “2.4 Fuel Injector Seals, Replacing”, page 288 .
ility ab y li an pt ce
–
ris tho u Always replace the combustion chamber seal (Teflonss aseal) af‐
