Golf 2015 ➤ , Golf Variant 2015 ➤ Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015 Procedure •
Engine/transmission assembly removed and secured on the Engine Support - T10497- .
– Remove the starter. Refer to ⇒ Electrical Equipment; Rep. Gr. 27 ; Starter; Starter, Removing and Installing .
– Remove the nuts -arrows-, and remove the front bracket from the transmission fluid pan. Note
n AG. Volkswagen AG do es n wage s k l ot g o yV ua b d ran ir se tee o h t or u ac a ss
ility ab y li an pt ce
un le
The threaded bolts are welded to the front of the oil pan.
Place a cleaning cloth underneath, to catch coolant leaking out. – Loosen the hose clamps -arrows-, remove the coolant hoses from the transmission fluid cooling circuit. – Remove the bolts -1- and set aside the Transmission Coolant Valve - N488- . – Seal the open lines and connections with clean plugs from the Engine Bung Set - VAS6122- . Note
AG.
Prote cted by
Rep. Gr.10 - Engine Assembly
agen lksw Vo by
c o p yri gh t . C op yi
22
ht rig py Co t.
r fo ng
Ignore Hose Clamps - Up To 25mm - 3094- .
rrectne s s o f i t to the co n form spec atio h re n wit i n thi sd o c um en
Note
urposes, in part or in wh ole, cial p is n mer m ot p o c erm or e t a itte v i r d p
– Disconnect the connector -2-.
