Golf 2015 ➤ , Golf Variant 2015 ➤ Engine Mechanical, Fuel Injection and
AG. Volkswagen AG d agen oes ksw not l o gu yV b ara d e nte is r o eo h ut ra a c s Ignition s - Edition 04.2015
rrectness of i t to the co nf o r m spec atio h re n in wit
– Remove the fuel rail. Refer to ⇒ “4.4 Fuel Rail, Removing and Installing, Direct Fuel Injec‐ tion”, page 309 . Removing Fuel Injectors, in the Event That They Are Stuck in the Fuel Rail Carefully remove the fuel injectors out of the fuel rail.
Removing Fuel Injectors, in the Event That They Are Stuck in the Cylinder Head – Cover the open intake channels with a clean cloth.
– Remove the electrical connector on the fuel injector that is about to be removed. – Push the Injector/Combustion Chamber Seal Tool Set - 18 T10133/18- over the fuel injector.
agen lksw Vo by
AG.
Prote cted by c o py rig ht . C op yi
Rep. Gr.24 - Multiport Fuel Injection
ht rig py Co t.
286
thi sd o cu m en
– Carefully hit the sleeve to loosen the fuel injector.
