Golf 2015 ➤ , Golf Variant 2015 ➤ Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015 Oxygen Sensor Heater - Z19❑ Component location. Refer to ⇒ Fig. ““ Oxygen Sensor 1 before Catalytic Converter -GX10- -1- ”“ , page 283 . ❑ Removing and installing. Refer to ⇒ “8.2 Oxygen Sensor 1 before Catalytic Converter GX10 , Removing and Installing”, page 333 . 6 - Turbocharger Recirculation Valve - N249- and Charge Pressure Actuator - V465❑ Components are installed directly on the turbocharger ❑ Component location. Refer to ⇒ “1.1 Overview - Turbocharger”, page 256 . ❑ Removing and installing. Refer to ⇒ “1.1 Overview - Turbocharger”, page 256 . 7 - Camshaft Position Sensor 3 - G300❑ 9 Nm ❑ Component location. Refer to ⇒ Fig. ““Ignition Coils and Adjusting Elements”“ , page 280 . ❑ Removing and installing. Refer to ⇒ “1.5.2 Camshaft Position Sensor 3 G300 , Removing and Installing”, page 360 . 8 - Brake Lamp Switch - F- and Brake Pedal Switch - F47❑ Component location. Refer to ⇒ Fig. ““Installed Location of the Brake Lamp Switch -F- / Brake Pedal Switch -F63- and Vacuum Sensor -G608- .”“ , page 279 . ag⇒ ❑ Removing and installing. Refer System; Rep. Gr. 45 ; Component Location Overview . . Volkswto en ABrake G gen AG does n
a lksw
es, in part or in w l purpos hole ercia , is n m m ot p o c erm or e t a itte iv r du rp o nl f e ng
ility ab y li an pt ce
ot g 9 - Connectors d by Vo ua ra e tee ris Sensor 1 before Catalytic Converter -nGX10❑ For Oxygen o h t or u a s ❑ For sOxygen Sensor 1 after Catalytic Converter - GX7- ac ❑ Component location. Refer to ⇒ Fig. ““Oxygen Sensors”“ , page 283 .
rrectness of i t to the co nf o r m spec atio h re n in wit
10 - High Pressure Pump with Fuel Pressure Regulator Valve - N276❑ Component location. Refer to ⇒ Fig. ““High Pressure Pump and Camshaft Position Sensor”“ , page 282 . ❑ High Pressure Pump Assembly Overview. Refer to ⇒ “7.1 Overview - High Pressure Pump”, page 325 . ❑ Removing and installing. Refer to ⇒ “7.2 High Pressure Pump, Removing and Installing”, page 328 . 11 - Engine Coolant Temperature Sensor - G62❑ Component location. Refer to ⇒ “2.3 Overview - Engine Coolant Temperature Sensor”, page 228 . ❑ Removing and installing. Refer to ⇒ “2.10 Engine Coolant Temperature Sensor G62 , Removing and Installing”, page 238 . 12 - Engine Control Module - J623❑ Removing and installing. Refer to ⇒ “6.1 Engine Control Module J623 , Removing and Installing”, page 321 . thi sd o cu m en
13 - Camshaft Position Sensor - G40❑ 9 Nm ❑ Component location. Refer to ⇒ Fig. ““View from Above”“ , page 281 . ❑ Removing and installing. Refer to ⇒ “1.5.1 Camshaft Position Sensor G40 , Removing and Installing”, page 360 . ht rig py Co t.
agen lksw Vo by
Prote cted by c o py rig ht . C op yi
14 - Channel Separating Plate Vacuum Diaphragm (Intake Manifold Flaps) ❑ Component location. Refer to ⇒ Fig. ““Variable Intake Manifold”“ , page 281 . AG.
15 - Connector for the Intake Manifold-Fuel Injector 16 - Intake Manifold Runner Control Valve - N316❑ Component location. Refer to ⇒ Fig. ““Variable Intake Manifold”“ , page 281 .
1. Fuel Injection System
