AG. Volkswagen AG d agen oes ksw not l o V gu by ara d e nte is r o h Engine Mechanical,eFuel or ut ac a ss
Removing
– Remove the ignition coils with power output stages cylinder “3”. Refer to ⇒ “1.3 Ignition Coils with Power Output Stages, Removing and Installing”, page 357 . – Release retainers in direction of -arrows- and remove wiring duct -1- from bracket.
– Clamp off the coolant hoses -arrows- with the Hose Clamps Up To 25mm - 3094- . – Loosen the clamps and remove the coolant hoses.
ht rig py Co t.
agen lksw Vo by
Prote cted by c o p yri gh t. C op yi
Installing
do c um en
– Remove the bolt -1- and remove the upper coolant pipe.
rrectness of i t to the co nform spec at i h re o n wit in t his
es, in part or in w l purpos hole ercia , is n m ot p om c r erm o e t a itte riv du p or nl f e g n
ility ab y li an pt ce
♦ Hose Clip Pliers - VAS6362-
Golf 2015 ➤ , Golf Variant 2015 ➤ Injection and Ignition - Edition 04.2015
Install in reverse order of removal. Note the following: AG.
Note
Secure hose connections with standard production clamps. Refer to the Parts Catalog. – Check the coolant level. Refer to ⇒ page 222 . Tightening Specifications ♦ Refer to ⇒ “3.1 Overview - Coolant Pipes”, page 241 .
3. Coolant Pipes
243
