Golf 2015 ➤ , Golf Variant 2015 ➤ Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015 . Volkswagen AG gen AG does not gu ara nte eo ra c
ris tho u a ss
– Free up the coolant hose -2-.
Prote cted by
Note
Place a cleaning cloth underneath, to catch coolant leaking out. – Disconnect the coolant hoses -1 and 2- with Hose Clamps Up To 25mm - 3094- . – Loosen the clamps and remove the coolant hoses. – Remove the bolts -arrows- and the front coolant pipe. Installing Install in reverse order of removal. Note the following: Note
Secure hose connections with standard production clamps. Refer to the Parts Catalog. – Check the coolant level. Refer to ⇒ page 222 . Tightening Specifications ♦ Refer to ⇒ “3.1 Overview - Coolant Pipes”, page 241 .
3.3
Upper Coolant Pipes, Removing and In‐ stalling
Special tools and workshop equipment required ♦ Hose Clamps - Up To 25mm - 3094-
242
Rep. Gr.19 - Cooling System
AG.
– Unclip the air guide lower section -1- and remove.
agen lksw Vo by
c o p yri gh t. C op yi
– Remove the left and right bolts -arrow-.
ht rig py Co t.
r fo ng
– Open the retaining tabs in direction of -arrows-, remove the upper air duct -1-.
rrectne s s o f i t to the co n form spec atio h re n wit i n thi sd o c um en
urposes, in part or in wh ole, cial p is n mer m ot p o c erm or e t a itte v i r d p
ility ab y li an pt ce
un le
wa the cover – Open the retainer in direction of -arrow- andVremove olks y b -2-. ed
