Golf 2015 ➤ , Golf Variant 2015 ➤ Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015 – Clamp the hose/line assembly -A- to the slave cylinder with the Hose Clamps - Up To 25mm - 3094- . – Pull hose/line assembly clip -arrow- out as far as stop. – Remove pipe/hose line assembly from the slave cylinder ven‐ tilator.
Vehicles with DSG® Transmission – Selector lever cable from the transmission and pull it out of the cable bracket. Refer to the ⇒ Controls, Housing; Rep. Gr. 34 ; Selector Mechanism; Selector Mechanism, Removing and In‐ stalling repair manual. – Disconnect the connector -2-. – Push back the B+ terminal protector -1- and disconnect the B + wire from the starter solenoid switch. – Remove the nut -3- and remove the ground wire. Note
Depending on the version the ground cable is attached to the starter bolt. AG. Volkswagen AG d agen o –
touch vehicle
es n ot g ua ground withrahand nte eo ra c
Continuation for All – Remove the bolts -arrows- for the transmission (about 2 turns).
rrectness of i t to the co nform spec at i h re o n wit in t his
– Disconnect the connector -4- for the DSG Transmission Me‐ chatronic - J743- , by turning screw connection counterclock‐ wise.
do c um en
es, in part or in w l purpos hole ercia , is n m ot p om c r erm o e t a itte riv du p or nl f e g n
– Do not touch contacts in transmission connector with hands.
ility ab y li an pt ce
ksw Vol by d e electricity, To discharge static ris tho (without gloves). u a ss
1. Engine, Removing and Installing
15
