Golf 2015 ➤ , Golf Variant 2015 ➤ Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015 Caution
This procedure contains mandatory replaceable parts. Refer to component overview prior to starting procedure. AG. Volkswagen A
n wage olks V by ed ris Mandatory Replacement Parts o th au ♦ Seal - Engine Oil Cooler ss
CAUTION
rrectness of i t to the co nf o r m spec atio h re n in wit
The coolant system is under pressure when the engine is warm. Risk of scalding due to hot steam and hot coolant. Possibility of burning or scalding the skin and other parts of the body. – Wear safety gloves. – Wear protective eyewear. – Reduce the pressure: cover the coolant reservoir cap with a cloth and carefully open. – Drain the coolant. Refer to ⇒ “1.3 Coolant, Draining and Filling”, page 217 . – Remove the auxiliary components bracket. Refer to ⇒ “1.5 Auxiliary Components Bracket, Removing and Instal‐ ling”, page 53 .
Prote cted by
Install in reverse order of removal. Note the following:
agen lksw Vo by
c o p yri gh t . C op yi
Installing
ht rig py Co t.
– Remove the bolts -4 and 5- and remove the engine oil cooler -3- together with the seal -2-.
thi sd o cu m en
es, in part or in w l purpos hole ercia , is n m m ot p o c erm or e t a itte iv r du rp o nl f e ng
ility ab y li an pt ce
Removing
G do es n ot g ua ran tee or ac
AG.
Note ♦ Always replace gaskets and seals. ♦ Secure hose connections with standard production clamps.
Refer to the Parts Catalog.
– Install the engine oil cooler -3- with a new seal -2-. – Install the accessory assembly bracket. Refer to ⇒ “1.5 Auxiliary Components Bracket, Removing and Instal‐ ling”, page 53 . – Fill with coolant. Refer to ⇒ page 218 . – Fill with engine oil and then check the level. Refer to ⇒ Main‐ tenance ; Booklet 36.1 ; Procedure Descriptions; Engine Oil, Draining, Replacing Oil Filter, and Filling . Tightening Specifications ♦ Refer to ⇒ “2.1 Overview - Engine Oil Cooler”, page 192 .
2. Engine Oil Cooler
193
