Golf 2015 ➤ , Golf Variant 2015 ➤ Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015
4.6
Valve Stem Seals, Removing and In‐ stalling
⇒ “4.6.1 Valve Stem Seals, Removing and Installing, Cylinder Head Installed”, page 163 . ⇒ “4.6.2 Valve Shaft Seals, Removing and Installing, Cylinder Removed”, page 166 .
4.6.1
Valve Stem Seals, Removing and In‐ stalling, Cylinder Head Installed
Special tools and workshop equipment required ♦ Spark Plug Removal Tool - 3122B♦ Puller - Valve Seal - 3364♦ Seal Installer - Valve Stem - 3365♦ Valve Cotter Tool Kit - Adapter - T40012♦ Torque Wrench 1331 5-50Nm - VAG1331♦ Valve Keeper Tool Kit - VAS5161A♦ Valve Cotter Tool Kit - Guide Plate 19B - VAS5161/19B♦ Valve Cotter Tool Kit Knurled Thumb Screws M6 VAS5161/12♦ Punch - VAS5161/3ARemove Valve Stem Seals – Remove the camshafts. Refer to ⇒ “4.2 Camshaft, Removing and Installing”, page 136 . – Mark the allocation of the roller rocker lever and the hydraulic adjusting elements so they can be installed again.
olkswagen AG en AG. V does not gu ara nte eo Removal Tool ra c
g – If necessary, remove the roller rocker levers witholkthe swahydraulic V y adjusting elements and place them on a clean b surface. ed
un le
ility ab y li an pt ce
r fo ng
– Move piston for that cylinder to “bottom dead center position”.
rrectne s s o f i t to the co n form spec atio h re n wit i n thi sd o c um en
urposes, in part or in wh ole, cial p is n mer m ot p o c erm or e t a itte v i r d p
– Install the Valve Cotter Tool Kit - Guide Plate 19B VAS5161/19B- with the Valve Cotter Tool Kit Knurled Thumb Screws M6 - VAS5161/12- as shown on the cylinder head.
ht rig py Co t.
ris
o thPlug – Remove the spark plugs using a Spark au s 3122B- . s
4. Valvetrain
163
