Golf 2015 ➤ , Golf Variant 2015 ➤ Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015 – Install the chain tensioner -1- and tighten the bolts -arrows-.
– Install the chain tensioner -2-. The wire clip -arrow- must come in to contact with the oil pan upper section opening. Tighten the bolt -1- and remove the Locking Pin (3 pc.) - T40011- .
– Turn the intake camshaft in the direction of the arrow -1- using the Adapter - T40266- until the Camshaft Lock - T40271/2-2- can be pushed out of the chain sprocket splines. Release the camshaft.
n AG. Volkswagen AG do es n wage s k l ot g o yV ua b d ran ir se tee o h t or u ac a ss
agen lksw Vo by
AG.
Prote cted by
c o p yri gh t . C op yi
Rep. Gr.15 - Cylinder Head, Valvetrain
ht rig py Co t.
128
do c um en
r te o iva r rp fo g n
rrectness of i t to the co nform spec a t i h re o n in wit thi s
es, in part or in w l purpos hole ercia , is n m ot com
pe rm itte d
– Check the adjustment. The painted chain links -arrows- must line up with the markings on the chain sprockets.
ility ab y li an pt ce
un le
– Remove the Camshaft Lock - Component 1 - T40271/1- and Camshaft Lock - Component 2 - T40271/2- .
