Golf 2015 ➤ , Golf Variant 2015 ➤ Engine Mechanical, Fuel Injection and Ignition - Edition 04.2015 Installing – Replace seals. AG. Volkswagen AG d – Install the cover on the cylinder head the tighten the bolts hand agen oes not tight. While doing so make sure that the seal lays correctly onVolksw gu y b ara d the cylinder head. e n s
ri ho
tee or ac
es, in part or in w l purpos hole ercia , is n m m ot p o c erm or e t a itte iv r du rp o nl f e ng
ility ab y li an pt ce
ut Refer – Tighten the bolts -1 through 6- in the sequence shown. sa s to ⇒ Fig. ““Timing Chain Guard Upper Cover - Tightening Se‐ quence”“ , page 105 .
rrectness of i t to the co nf o r m spec atio h re n in wit
– Install the Camshaft Adjustment Valve 1 - N205- and Exhaust Camshaft Adjustment Valve 1 - N318- . Refer to ⇒ “4.4 Camshaft Adjustment Valve 1 N205 and Exhaust Cam‐ shaft Adjustment Valve 1 N318 , Removing and Installing”, page 161 . – Install the engine cover. Refer to ⇒ “3.1 Engine Cover, Removing and Installing”, page 38 . Tightening Specifications
♦ Refer to ⇒ “2.1 Overview - Timing Chain Cover”, page 104
2.2.2
Lower Timing Chain Cover, Removing and Installing
♦ Vibration Damper Assembly Tool - T10531-
♦ Cover - Lower Timing Chain ♦ Bolts - Lower Timing Chain Cover ♦ O-ring - Oil Dipstick Tube Note
Dependent on the sealing compound sealant, bends the cover when removing. Because of this, always replace the cover. Removing – Remove right front wheel housing liner. Refer to ⇒ Body Ex‐ terior; Rep. Gr. 66 ; Wheel Housing Liner; Front Wheel Hous‐ ing Liner, Removing and Installing . – Remove the engine support. Refer to ⇒ “1.6 Engine Support, Removing and Installing”, page 55 . – Remove the vibration damper. Refer to ⇒ “1.4 Vibration Damper, Removing and Installing”, page 47 . – Drain the engine oil. Refer to ⇒ Maintenance ; Booklet 36.1 ; Procedure Descriptions; Engine Oil, Draining, Replacing Oil Filter, and Filling .
108
Rep. Gr.15 - Cylinder Head, Valvetrain
AG.
Mandatory Replacement Parts
agen lksw Vo by
Prote cted by c o py rig ht . C op yi
This procedure contains mandatory replaceable parts. Refer to component overview prior to starting procedure.
ht rig py Co t.
Caution
thi sd o cu m en
Special tools and workshop equipment required
