Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 12 - Bolt ❑ Renew after removal ❑ 50 Nm +90° 13 - Gearbox mounting ❑ Removing and installing ⇒ “2.3.2 Removing and installing gearbox mounting, Ibiza 2018, Arona”, page 80 14 - Bolt ❑ Renew after removal ❑ 3 off ❑ 40 Nm +90° 15 - Gearbox bracket Engine support - specified torque and tightening sequence Note
Risk of damage to threads by starting bolts at an angle. – Tighten bolts in stages in the sequence shown. Stage 1. 2. 3.
Bolts -1 … 3-1 … 3-1 … 3-
Specified torque/turning further angle 7 Nm 40 Nm Turn 90° further
Pendulum support - specified torque and tightening sequence Note Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not If a further tightening angle is specified forbycertain these permitted unless authorised SEAT S.A.bolts, SEAT S.A does not guarantee or accept any liability with must be renewed. respect to the correctness of information in this document. Copyright by SEAT S.A.
– Tighten bolts in stages in the sequence shown: Sta ge 1. 2. 3.
Bolts -2- and -3-4-2-, -3- and -4-
Specified torque/turning further angle 50 Nm 130 Nm Turn 90° further
2. Assembly mountings
