Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 ❑ Tighten threaded connections evenly ⇒ “1.6 Installation position of clamp”, page 453 13 - Nut ❑ 23 Nm Installing catalytic converter - specified torque and tightening se‐ quence 1.
– Fit catalytic converter to tur‐ bocharger, attach screw-type clip -arrow- without tightening – Screw in bolts -1, 2, 3- loosely • by hand
2.
3.
It should still be possible to move catalytic converter and bracket.
– Tighten screw-type clip 15 Nm -arrow-. – Tighten bolts and nuts in the 20 Nm sequence -1 to 3-.
4.
2.2
Removing and installing catalytic con‐ verter
⇒ “2.2.1 Catalytic converter - removing and installing, Leon 2013, Ibiza 2018, Arona”, page 459 ⇒ “2.2.2 Catalytic converter - removing and installing, Toledo 2013, Ibiza 2016”, page 461
2.2.1
Catalytic converter - removing and in‐ stalling, Leon 2013, Ibiza 2018, Arona
Special tools and workshop equipment required ♦ Torque wrench - V.A.G 1331-
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A.
♦ High-temperature paste ⇒ Electronic parts catalogue (ETKA) . Note
The catalytic converter is removed together with the front exhaust pipe.
2. Exhaust gas cleaning
459
