Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 – Slacken nuts on front clamp -arrows-.
– Push exhaust system towards front until preloading at mount‐ ing for exhaust pipe -a- = 5 mm. – Fit front clamp ⇒ “1.6 Installation position of clamp”, page 453 . Specified torquesProtected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to the correctness of information in this document. Copyright by SEAT S.A. ♦ Clamp ⇒ page 454
1.5
Checking exhaust system for leaks
Procedure – Start engine, and run at idling speed. – Seal exhaust pipes with cloths or plugs, for example, for the duration of the leakage test. – Check (by listening) points of connection between exhaust manifold and the cylinder head, between turbocharger and front exhaust pipe etc. to make sure there are no leaks. – Repair any leaks found.
1.6
Installation position of clamp Note
Make sure to use clamps with continuous clip only.
1. Exhaust pipes, silencers
453
