Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 1 - Clamp ❑ Fitting position ⇒ “1.6 Installation posi‐ tion of clamp”, page 453 ❑ Position ⇒ page 454 ❑ Specified torque ⇒ page 454 2 - Front silencer ❑ Removing and installing ⇒ “1.3.2 Removing and installing front silencer, Ibiza 2018, Arona”, page 446 3 - Mounting ❑ Renew if damaged 4 - Support 5 - Securing bolt Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not ❑ permitted 20 Nm unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A.
6 - Separating point ❑ Separating ⇒ “1.2.2 Separating ex‐ haust pipes from silenc‐ ers, Ibiza 2018, Arona”, page 441
7 - Rear silencer ❑ Removing and installing ⇒ “1.3.5 Removing and installing back silencer, Ibiza 2018, Arona”, page 450 8 - Mounting ❑ Renew if damaged 9 - Support 10 - Support 11 - Securing bolt ❑ 20 Nm
438
Rep. gr.26 - Exhaust system
