Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 ♦ Lambda probe open ring spanner set - 3337-

♦ Safety gloves Removing – Disconnect corresponding connector -arrow-: Conector marrón - Lambda probe before catalytic converter GX10Conector negro - Lambda probe after catalytic converter - GX7-

– Unscrew corresponding Lambda probe using a tool from Lambda probe open ring spanner set - 3337- . 1-

Lambda probe 1 after catalytic converter - GX7-

Lambda probe 1 before catalytic converter - GX10-

Installing Install in reverse order of removal, observing the following: Note ♦ New lambda probes are coated with an assembly paste. This

paste must not get into the slots on the Lambda probe body.

♦ In the case of a used Lambda probe, grease only the thread

with high-temperature paste. This paste must not get into the Protected by copyright. Copying slots on the Lambda probe body. High-temperature paste ⇒for private or commercial purposes, in part or in whole, is not unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with Electronic parts catalogue (ETKA) . permitted respect to the correctness of information in this document. Copyright by SEAT S.A.

♦ During installation, the electrical connecting cable of the

Lambda probe must be secured at the same points. The elec‐ trical wiring must be prevented from touching the exhaust pipe.

Specified torque ♦ ⇒ “8.1.2 Assembly overview - lambda probe, Toledo 2013, Ibiza 2016”, page 430

434

Rep. gr.24 - Mixture preparation - injection
