2016 Seat Ibiza Workshop Manual - PDF DOWNLOAD

Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 – Thoroughly clean throttle valve connection, especially around closed throttle valve -arrows- using commercially available acetone to DIN 53247 and a brush. – Wipe out throttle valve housing with a lint-free cloth. – Allow acetone to dry off completely. – Install throttle valve module - GX3⇒ “4.3 Removing and installing throttle valve module GX3 ”, page 402 . – Delete learnt values, and adapt engine control unit - J623- to throttle valve module - GX3- . – Switch on ignition and select and run the following menu items at ⇒ Vehicle diagnostic tester: ♦ 0001 - Delete learnt values ♦ 0001 - Adaption of throttle valve module - J338

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A.

404

Rep. gr.24 - Mixture preparation - injection
