Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 10 - Seals ❑ Renew after removal 11 - Bolt ❑ Specified torque and tightening sequence ⇒ page 400 12 - O-ring ❑ Renew after removal 13 - Bolt ❑ Repair solution when retaining tabs have broken off ❑ Thread-forming ❑ Fit and screw in bolt by hand so that it screws into old thread Then tighten bolt to torque. ❑ 7 Nm 14 - Intake manifold sender - GX9❑ Removing and installing ⇒ “5.3 Removing and installing intake manifold sender GX9 ”, page 408 15 - Vacuum line 16 - O-ring ❑ If damaged, renew entire vacuum line ⇒ Item 15 (page 400) Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with 17 - Hose respect to the correctness of information in this document. Copyright by SEAT S.A. ❑ For crankcase ventilation.
Intake manifold - specified torque and tightening sequence – Tighten bolts in stages as follows: Stage
Bolts
Specified torque
1.
-Arrows-
2.
-Arrows-
Starting in centre, screw in bolts alter‐ nately by hand until they make contact Starting in centre, screw in bolts alter‐ nately to 8 Nm
Note
-Items 1, 2- can be disregarded.
4.2
Removing and installing intake manifold
Special tools and workshop equipment required ♦ Hose clip pliers - VAS 6362-
400
Rep. gr.24 - Mixture preparation - injection
