Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 11 - Air filter upper part ❑ Remove dirt, leaves and salt residues 12 - Bump stop ❑ check for damage and renew if necessary ❑ Make sure it is firmly seated after installation 13 - Air filter lower part ❑ Remove dirt, leaves and salt residues 14 - Bolt ❑ 9 off ❑ 1.5 Nm 15 - Water drain hose ❑ Cleaning 16 - Filter 17 - O-ring ❑ Renew if damaged 18 - Water drain hose ❑ With valve ❑ Cleaning 19 - Bolt ❑ 2 off ❑ 2 Nm
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A.
394
Rep. gr.24 - Mixture preparation - injection
