Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 5 - O-ring ❑ Renew after removal ❑ Lubricate with clean engine oil. 6 - Spacer ring ❑ Renew if damaged 7 - Injector ❑ Removing and installing ⇒ “2.3 Removing and installing injectors”, page 386 8 - Combustion chamber seal ❑ Do not treat with grease or other lubricant. ❑ Renewing ⇒ “2.3 Removing and installing injectors”, page 386 9 - High-pressure pipe ❑ Renew after removal ❑ Unions must be free of damage ❑ Do not alter shape. ❑ Removing and installing ⇒ “7.3 Removing and installing high-pressure pipe”, page 427 ❑ Lubricate thread of union nuts with clean engine oil ❑ 16 Nm + 45° Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A.
2.2
Removing and installing fuel rail
Removing – Remove intake manifold ⇒ page 400 . – Remove high-pressure pipe ⇒ page 427 . – Seal lines so that no dirt can enter fuel system. Vehicles with radiator, version 1 – Unplug electrical connector -1-. – Unscrew bolts -arrows-, and carefully pull fuel rail -2- off in‐ jectors.
2. Injectors
385
