Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 1 - Inlet camshaft control valve 1 - N205❑ Assembly overview ⇒ “3.1 Assembly over‐ view - valve gear”, page 204 2 - Exhaust camshaft control valve 1 - N318❑ Assembly overview ⇒ “3.1 Assembly over‐ view - valve gear”, page 204 3 - Activated charcoal filter sol‐ enoid valve 1 - N804 - Ignition coil 1 with output stage - N70❑ Assembly overview ⇒ “1.1 Assembly over‐ view - ignition system”, page 464 5 - Ignition coil 2 with output stage - N127❑ Assembly overview ⇒ “1.1 Assembly over‐ view - ignition system”, page 464 6 - Ignition coil 3 with output stage - N291❑ Assembly overview ⇒ “1.1 Assembly over‐ view - ignition system”, page 464 7 - Hall sender 3 - G163❑ Assembly overview ⇒ “1.1 Assembly over‐ view - ignition system”, page 464 8 - Hall sender - G40- (camshaft position sensor) ❑ Assembly overview ⇒ “1.1 Assembly overview - ignition system”, page 464 9 - Fuel metering valve - N290❑ Assembly overview ⇒ “7.1 Assembly overview - high-pressure pump”, page 425 Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
10 - Injector, cylinder 3 - N32respect to the correctness of information in this document. Copyright by SEAT S.A. ❑ Assembly overview ⇒ “2.1 Assembly overview - fuel rail with injectors”, page 383 11 - Injector, cylinder 2 - N31❑ Assembly overview ⇒ “2.1 Assembly overview - fuel rail with injectors”, page 383 12 - Injector, cylinder 1 - N30❑ Assembly overview ⇒ “2.1 Assembly overview - fuel rail with injectors”, page 383
380
Rep. gr.24 - Mixture preparation - injection
