Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 – Pull off electrical connector -arrows- for charge pressure po‐ sitioner - V465- . – Loosen clear wiring harness from the retaining clips -5- and depending on the version the coolant hose -4- as well, and push them to one side. – Unscrew screw -1- with the torque wrench - VAS 6854- , the ratchet 1/4" - VAS 6234- and the socket bit Torx T 30 - T10405-2-. – Seal open lines and unions with clean plugs from engine seal‐ ing plug set - VAS 6122- . – Pull union -3- towards left of turbocharger, and carefully re‐ move it upwards. Installing Install in reverse order of removal, observing the following: Note
Renew O-rings. Specified torques ♦ ⇒ “3.1 Assembly overview - air filter housing”, page 393 ♦ ⇒ “1.1 Assembly overview - turbocharger”, page 351
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A.
362
Rep. gr.21 - Turbocharging/supercharging
