2016 Seat Ibiza Workshop Manual - PDF DOWNLOAD

Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 ♦ Torque wrench - VAS 6854-

♦ Ratchet insert 1/4" - VAS 6234-

Removing – Remove air filter housing ⇒ page 397 . – Press release tabs on both sides, and disconnect hose -2- for activated charcoal filter. Note

Risk of chemical damage to the coolant pump gasket caused by oil entering between the coolant pump and the cylinder head. – Cover coolant pump with a cloth. Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with – permitted Unscrew -arrows-, and detach crankcase breather hose respectbolts to the correctness of information in this document. Copyright by SEAT S.A. -1-.

1. Turbocharger

361
