Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018

4.6

Removing and installing radiator fan V7-

⇒ “4.6.1 Radiator fan V7 removing and installing, Leon 2013, Ibiza 2018, Arona”, page 341 ⇒ “4.6.2 Radiator fan V7 removing and installing, Toledo 2013, Ibiza 2016”, page 341

4.6.1

Radiator fan - V7- removing and instal‐ ling, Leon 2013, Ibiza 2018, Arona

Removing – Remove radiator cowl ⇒ “4.5 Removing and installing radiator cowl”, page 335 . – Remove electrical line from the wire guide. – Unscrew nuts -arrows-, and remove radiator fan - V7- . Installing Install in reverse order of removal, observing the following: – Install radiator cowl ⇒ “4.5 Removing and installing radiator cowl”, page 335 . Specified torques ♦ ⇒ “4.1 Assembly overview - radiator/radiator fan”, page 304

4.6.2

Radiator fan - V7- removing and instal‐ ling, Toledo 2013, Ibiza 2016

Removing

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A.

– Remove radiator cowl ⇒ “4.5.3 Radiator cowl - removing and installing, Toledo 2013, Ibiza 2016”, page 339 . – Push through clamping pins -arrows-, and remove fan ring -1-.

– Remove electric cable -1- from cable guide. – Unscrew nuts -arrows-, and remove radiator fan - V7- . Installing Install in reverse order of removal, observing the following: – Install radiator cowl ⇒ “4.5.3 Radiator cowl - removing and installing, Toledo 2013, Ibiza 2016”, page 339 . Specified torques ♦ ⇒ “4.1.4 Assembly summary - radiator/radiator fan, Toledo 2013, Ibiza 2016”, page 310

4. Radiator, radiator fan

341
