Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 ♦ Engine bung set - VAS 6122-
Removing Arona – Remove front bumper cover ⇒ General body repairs, exterior; Rep. gr. 63 ; Front bumper; Removing and installing front bumper cover . Continued for all vehicles – Release hose clip -1-, and pull air hose -2- off air filter housing. – Unscrew bolts -3- on both sides. – Release locking lugs -arrow-, unclip air hose -4- from the front end and remove on both sides in -direction of the arrow-. CAUTION Risk of injury; the radiator fans can run at any time. – Separate electrical connector. – Remove electrical connector -arrow- from radiator fan.
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A.
Vehicles with radiator, variant 2 – Place drip tray for workshop hoist - VAS 6208- beneath en‐ gine. – Disconnect connector -1- on radiator outlet coolant tempera‐ ture sender - G83- . – Slightly lift retaining clip -3-, disconnect coolant hose from ra‐ diator (top right) and drain off coolant. – Slightly lift retaining clips -arrows-, disconnect coolant hoses from radiator and drain off remaining coolant. – Seal open lines and unions with clean plugs from engine seal‐ ing plug set - VAS 6122- .
4. Radiator, radiator fan
337
