Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 Vehicles with radiator mounting carrier, bolted – If fastener was cut off, bolt radiator mountings to lock carrier. Bolts -2- ⇒ Electronic parts catalogue (ETKA) . •

Specified torque: 5 Nm

Continued for all vehicles – Install coolant radiator. Engage radiators with one another. Ensure proper engagement by pulling. – Fit headlight rails ⇒ Electrical system; Rep. gr. 94 ; Lights, bulbs, switches - exterior; Removing and installing headlights, headlight rails . – Install front bumper cover ⇒ General body repairs, exterior; Rep. gr. 63 ; Front bumper; Removing and installing front bumper . – Install radiator cowl ⇒ “4.5.2 Removing and positioning the radiator cowl, Arona, Ibiza 2018”, page 336 . – Connect coolant hose with plug-in connector ⇒ page 308 . – Add coolant ⇒ page 269 . Specified torques ♦ ⇒ “4.1 Assembly overview - radiator/radiator fan”, page 304 ♦ ⇒ “3.1.2 Assembly overview - air filter housing, Ibiza 2018, Ar‐ ona”, page 395 ♦ ⇒ Electrical system; Rep. gr. 94 ; Lights, bulbs, switches exterior; Headlights; Assembly overview - headlights, head‐ light rails . ♦ ⇒ Electrical system; Rep. gr. 94 ; Headlight; exploded view: headlight .

4.5

Removing and installing radiator cowl

⇒ “4.5.1 Removing and positioning the radiator cowl, Ateca, Leon 2013”, page 335 ⇒ “4.5.2 Removing and positioning the radiator cowl, Arona, Ibiza 2018”, page 336 ⇒ “4.5.3 Radiator cowl - removing Protected by copyright. Copying for and privateinstalling, or commercial Toledo purposes, in2013, part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with Ibiza 2016”, page 339

4.5.1

respect to the correctness of information in this document. Copyright by SEAT S.A.

Removing and positioning the radiator cowl, Ateca, Leon 2013

Removing CAUTION Risk of injury; the radiator fans can run at any time. – Separate electrical connector.

4. Radiator, radiator fan

335
