Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 ♦ Oil pressure sensor G10

4.4

Removing and installing oil filter housing

Special tools and workshop equipment required ♦ Oil filter tool - 3417-

Removing – Drain engine oil ⇒ “1.2 Engine oil:”, page 237 . – Remove oil filter -arrow- with oil filter tool - 3417- . Installing – Fill oil filter with engine oil and tighten it to specified torque using oil filter tool - 3417- ⇒ page 254 .

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A.

Note

If connecting union -2- in sump -1- became loose, retighten it as described below ⇒ page 252 – Fill with engine oil and check oil level ⇒ “1.2 Engine oil:”, page 237 . Specified torque for oil filter Component

Specified torque

Conditions

Oil filter

20 Nm

Coat gasket with engine oil.

4.5

Removing and installing oil pressure regulating valve - N428-

Removing Note

Attach all heat-shielding sleeves in the same places when instal‐ ling. – Detach heat insulation sleeves.

254

Rep. gr.17 - Lubrication
