Oil filter, oil pressure switch
⇒ “4.1 Assembly overview - oil filter, oil pressure switch”, page 251 ⇒ “4.2 Removing and installing oil pressure sender G10 ”, page 252 ⇒ “4.3 Checking oil pressure and oil pressure switch”, page 253 ⇒ “4.4 Removing and installing oil filter housing”, page 254 ⇒ “4.5 Removing and installing oil pressure regulating valve N428 ”, page 254
4.1
Assembly overview - oil filter, oil pressure switch
1 - Oil filter ❑ See note ⇒ “1.1 Assembly over‐ view - sump/oil pump”, page 233 . ❑ Removing and installing ⇒ “4.4 Removing and in‐ stalling oil filter hous‐ ing”, page 254 ❑ Tighten loosened con‐ necting union for oil filter ⇒ Fig. ““Tightening con‐ necting union for oil fil‐ ter”“ , page 236 2 - Threaded sleeve ❑ If connecting union for oil filter in sump became loose ⇒ page 252 Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with 3 - Oil pressurepermitted sender - G10respect to the correctness of information in this document. Copyright by SEAT S.A. ❑ Switch pressure 0.3 to 0.6 bar ❑ Insulation, black ❑ Check in Guided fault finding ⇒ Vehicle di‐ agnostic tester ❑ Removing and installing ⇒ “4.2 Removing and in‐ stalling oil pressure sender G10 ”, page 252 ❑ Renew after removal ❑ 10 Nm +45°
4 - Seal ❑ Renew after each re‐ moval ⇒ Electronic Parts Catalogue 5 - O-rings ❑ No replacement part ❑ In case of leakage, renew valve ⇒ Item 7 (page 252) 6 - Bolt ❑ 8 Nm 4. Oil filter, oil pressure switch
