Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 – On first oil change, oil drain plug with captive seal -1- is dis‐ posed of. – Fit new oil drain plug -3- with renewable seal -2-. Oil drain plug with renewable seal (all future oil change services)
– Unscrew oil drain plug -2-, and dispose of old seal -3-. – New oil seal -1- can be renewed individually when oil is changed in the future.
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A.
Tightening connecting union for oil filter •
If the connecting union -2- in the top section of sump -1- is loose, retighten it as described below.
Use only the two nuts -3 and 4- for this procedure. •
Hexagon nut , qty. 2, ⇒ Electronic Parts Catalogue (ETKA)
– Screw nuts -3- and -4- onto connecting union -2-, and counter lock them. – Tighten connecting union -2- via nut -3-. – Loosen the two nuts and remove them, taking care not to loosen the connecting union. Specified torques
236
Threaded sleeve
Specified torque
-2-
50 Nm
Rep. gr.17 - Lubrication
