2016 Seat Ibiza Workshop Manual - PDF DOWNLOAD

Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 – Bolt guide plate -VAS 5161A/32- onto cylinder head again. – Insert assembly cartridge -VAS 5161A/32-1- with sleeve -VAS 5161A/32-2- into guide plate. – Press pressure fork downwards and pull knurled screw up‐ wards, turning it clockwise and anticlockwise. The valve cones are mounted in this way. – Reduce pressure on pressure fork whilst pulling on knurled screw. – Repeat procedure on each valve. Installing Assembly is carried out in the reverse order, note the following: – Install turbocharger ⇒ “1.2 Removing and installing turbocharger”, page 353 . – Install plenum chamber cover ⇒ General body repairs, exte‐ rior; Rep. gr. 50 ; Bulkhead; Removing and installing plenum chamber cover . Installing bulkhead of plenum chamber cover ⇒ General body repairs, exterior; Rep. gr. 50 ; Bulkhead; Removing and installing bulkhead . Toledo 2013, Ibiza 2016

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not

permittedplenum unless authorised by SEAT S.A. SEAT does not guarantee or accept any liability with – Install chamber cover ⇒ S.A General body repairs, exte‐ respect to the correctness of information in this document. Copyright by SEAT S.A. rior; Rep. gr. 55 ; front lid, rear lid, central locking; rust under wiper: remove and install

– Install engine control unit ⇒ “6 Engine (motor) control unit”, page 412 . – Install plenum chamber cover ⇒ General body repairs, exte‐ rior; Rep. gr. 55 ; front lid, rear lid, central locking; plenum chamber cover noise insulation covering; remove and install Continued for all vehicles – Install camshaft housing ⇒ “1.4 Removing and installing camshaft housing”, page 166 . – Install spark plugs ⇒ “1.1 Assembly overview - ignition system”, page 464 . Specified torques ♦ ⇒ “1.1 Assembly overview - turbocharger”, page 351 ♦ ⇒ Running gear, axles, steering; Rep. gr. 40 ; Drive shaft; Assembly overview: drive shaft

3.7.2

Removing and installing valve stem seals (cylinder head removed)

Special tools and workshop equipment required

226

Rep. gr.15 - Cylinder head, valve gear
