Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 Counter-hold tool - T10554•
Pins -1- and -2- are located at different distances to the coun‐ ter-hold tool - T10554- .
•
The counter-hold tool - T10554- can be inserted in only one position.
•
Fit counter-hold tool - T10554- so that it rests flat against cam‐ shaft adjusters.
Procedure Note ♦ Protect the toothed belt from escaping engine oil. ♦ Seal camshaft adjusters immediately using suitable plug from
engine bung set - VAS 6122- .
– Place a cloth underneath to catch escaping engine oil. – Thoroughly clean any cavities which have been filled with en‐ gine oil. – Set engine to “TDC for cylinder no. 1” ⇒ “4.7 Setting piston to TDC position”, page 155 . – Unscrew bolt -1-. – Release clips -2-. – Unclip bracket -4-. – Remove toothed belt cover -3-.
– Unscrew bolts -arrows- of exhaust camshaft. – The camshaft must be turned to gain access to all bolts. – Remove camshaft clamp - T10494- before turning camshaft. – After camshaft clamp - T10494- has been removed, turn cam‐ shaft until all remaining bolts haveCopying been for reached. Protected by copyright. private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
respect to theadjuster correctnessof of information this document. Copyright by SEAT S.A. – Remove cover from camshaft exhaustin camshaft.
– Set engine to “TDC for cylinder no. 1”, and insert camshaft clamp - T10494- ⇒ “2.5 Checking valve timing”, page 187 . Note
The camshaft clamp - T10494- must not be used as a counterhold tool.
200
Rep. gr.15 - Cylinder head, valve gear
