Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018
2.2
Assembly overview - toothed belt
1 - Toothed belt ❑ Do not bend toothed belt further than the speci‐ fied bend radius ⇒ Fig. ““Bend radius of toothed belt”“ , page 203 ❑ Before removing, mark direction of rotation with chalk or felt-tipped marker pen. ❑ Check for wear ❑ Removing ⇒ “2.3 Removing and in‐ stalling toothed belt”, page 176 ❑ Detaching from cam‐ shaft ⇒ “2.7 Removing tooth‐ ed belt from camshaft”, page 198 ❑ Installing (adjusting valve timing) ⇒ “2.6 Adjusting valve Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not timing”, page 189
permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
2 - Bolt respect to the correctness of information in this document. Copyright by SEAT S.A. ❑ 25 Nm ❑ When setting the speci‐ fied torque on the torque wrench - VAS 6583- , the length indicated on the insert tool - T10500must be entered in the torque wrench. 3 - Tensioning pulley ❑ Removing and installing ⇒ page 203 4 - Bolt ❑ Renew after removal ❑ 8 Nm +45° 5 - Cap 6 - O-ring ❑ Renew after removal 7 - Bolt ❑ Renew after removal ❑ 50 Nm +135° 8 - Exhaust camshaft toothed belt pulley ❑ With camshaft adjuster ❑ Removing and installing ⇒ page 211 9 - Diamond disk ❑ Renew after removal
174
Rep. gr.15 - Cylinder head, valve gear
