Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 ♦ Torque wrench - V.A.G 1331-

♦ Socket wrench - T10545-

Removing – Remove sump ⇒ “1.3 Removing and installing sump”, page 237 . – Turn crankshaft via vibration damper securing bolt in direction of engine rotation until the respective bolt is accessible. Note Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not ♦ The crank web of the respective cylinder must be positioned permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with

so that the socket - T10545- can betoinserted in ofthe pressure respect the correctness information in this document. Copyright by SEAT S.A. relief valve as close to vertical as possible.

♦ Furthermore, the corners of the socket - T10545- and of the

pressure relief valve must engage well.

– Unscrew pressure relief valve -1- using hexagon bit - T10545- . – Remove oil spray jets -2-. Installing

NOTICE Risk of damage to oil spray jets caused by deformation. – Do not bend oil spray jets.
