Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018
3
Crankshaft
⇒ “3.1 Crankshaft dimensions”, page 145 ⇒ “3.2 Renewing needle bearing in crankshaft”, page 145
3.1
Crankshaft dimensions Note
♦ Risk of deformation of bearing pedestals. ♦ The crankshaft must not be removed. ♦ Just loosening the main bearing caps will cause deformation
of the cylinder block bearing seats.
♦ This deformation will cause a reduction of the bearing clear‐
ance.
♦ Even if the bearing shells are not renewed, bearing damage
could occur due to a different bearing clearance.
♦ If the bearing cap bolts are loosened, the cylinder block must
be renewed complete with the crankshaft.
♦ Measuring the main bearing clearance is not possible with
normal workshop equipment.
Honing dimension Basic dimension
3.2
Conrod journal ∅ mm 47.80 -0.022 -0.037
Renewing needle bearing in crankshaft
Only vehicles with a dual clutch gearbox Special tools and workshop equipment required ♦ Counter support e.g. KUKKO 22-1 - VAS 251 621-
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A.
3. Crankshaft
145
