Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 Version 2 – Turn tensioning device in -direction of arrow-, and pull out locking pin - T10060 A- . Continued for all vehicles – Release tensioner. – Check that poly V-belt is properly seated. – Start engine and check that poly V-belt runs properly. Specified torques ♦ Securing bolts for noise insulation ⇒ General body repairs, exterior; Rep. gr. 66 ; Noise insulation; Assembly overview noise insulation ♦ Noise insulation assembly bolts, Toledo 213, Ibiza 2016 ⇒ General body works, exterior; Rep. gr. 50 ; Underbody pro‐ tection; Assembly overview: underbody protection

1.3

Removing and installing tensioner for poly V-belt

⇒ “1.3.1 Removing and installing tensioner for poly V-belt, vehi‐ cles without air conditioner compressor”, page 116 ⇒ “1.3.2 Removing and installing tensioner for poly V-belt, vehi‐ cles with air conditioner compressor”, page 117

1.3.1

Removing and installing tensioner for poly V-belt, vehicles without air condi‐ tioner compressor

Special tools and workshop equipment required ♦ Torque wrench - V.A.G 1331-

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A.

♦ Ratchet 1/2" x 9-12" Ref.(735/10) - VAG 1331/1-
