Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 4 - Tensioning device for poly V-belt ❑ Pivot with socket to slacken poly V-belt ❑ Lock with locking tool - T10060 A- . ❑ Removing and installing ⇒ “1.3.2 Removing and installing tensioner for poly V-belt, vehicles with air conditioner compressor”, page 117 5 - Bolt ❑ Renew after removal ❑ 20 Nm +90° 6 - Bolt ❑ Tightening torque ⇒ Electrical system; Rep. gr. 27 ; Alternator; Alternator: Exploded view 7 - Alternator ❑ removing and installing ⇒ Electrical system; Rep. gr. 27 ; Alternator; Removing and installing alternator . ❑ With freewheel ❑ Depending on the type and version of the alternator different overrunning alternator pulleys -A- and -Bmay be installed: correspondence ⇒ page 112 . ❑ The length of the poly V-belt must be determined depending on the design of the overrunning alternator pulley in accordance with the ⇒ Electronic Parts Catalogue (ETKA) . 8 - Dowel sleeve ❑ For air conditioner compressor. 9 - Air conditioner compressor ❑ Do not unscrew or disconnect refrigerant lines ❑ Removing and installing ⇒ Heating, air conditioning system; Rep. gr. 87 ; Air conditioner compressor; Removing and installing air conditioner compressor from and to bracket 10 - Bolt ❑ Specified torque ⇒ Heating, air conditioning; Rep. gr. 87 ; Air conditioner compressor; Assembly over‐ view - drive unit of air conditioner compressor . Allocation of overrunning alternator pulley
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with respect to the correctness of information in this document. Copyright by SEAT S.A.
112
Rep. gr.13 - Crankshaft group
