REPAIR INSTRUCTIONS 303
Figure 303 — Cylinder Head Alignment 1. Straightedge 2. Cylinder Head
Refer to Figure 304. 6. Torque all head mounting capscrews in three stages to the specified torque. a.
Torque all head mounting capscrews in sequence to 50 lb-ft (68 N•m) using torque wrench J 24407, or equivalent.
b.
Torque all head mounting capscrews in sequence to 125 lb-ft (170 N•m) using torque wrench J 24407, or equivalent.
c.
Torque all head mounting capscrews in sequence to final torque value of 195–215 lb-ft (264–292 N•m) using torque wrench J 24407, or equivalent.
3. Cylinder Block
8. After completing the run-in procedure, retorque the cylinder head capscrews in sequence, breaking each loose one at a time and then bringing it up to the specified torque.
7. Perform the engine run-in procedure, bringing temperatures up to the normal operating range.
