REPAIR INSTRUCTIONS Crankshaft Front Seal Installation After the oil pump has been installed, check the backlash between the auxiliary shaft gear and the oil pump driven gear.
SPECIAL TOOL REQUIRED r
Crankshaft Front Seal Installer J 37715-A
INSTALLATION PROCEDURE 3. Check the auxiliary shaft gear to oil pump driven gear backlash, 0.006–0.016 inch (0.15–0.41 mm), using a thickness gauge between the auxiliary shaft gear and the oil pump driven gear.
Timing Gear Cover Installation
Refer to Figure 296. 1. Position the lip-type seal on the seal installer, with the solid portion of the seal outward (toward the tool). 2. Position the tool over hub and into the seal opening. 296
With the crankshaft, camshaft and auxiliary driveshaft in place, install the timing gear cover. Remove the injection pump cover (if installed) from the timing cover to allow access to the injection pump drive gear during injection pump installation. 1. Apply a light coat of Silastic to the timingcover mounting surface. 2. Position the timing cover on the cylinderblock mounting surface.
Some mounting capscrews cannot be installed until the injection pump is installed. 3. Secure the timing cover to the cylinder block using the mounting capscrews. Torque the capscrews to 40 lb-ft (54 N•m) using torque wrench J 24407, or equivalent. 4. Position the front pedestal mount on the timing cover and secure with the mounting hardware. Torque the front support bracket (pedestal mounting) capscrews to 70 lb-ft (95 N•m) using torque wrench J 24407, or equivalent. Figure 296 — Crankshaft Front Seal Installation 1. Front Cover Seal 2. Seal Installer J 37715-A
3. Front Cover
3. Insert the hub capscrew into the hole in the seal installation tool and draw the seal in until the tool bottoms out on the face of the crankshaft. 4. Remove the tool and check the seal to ensure it has been evenly installed.
