REPAIR INSTRUCTIONS INJECTION NOZZLE HOLDER INSERT The injection nozzle holder insert is machined to provide a press fit in cylinder head. Insert Removal 1. To remove injection nozzle holder insert, tap ID with 3/4-10 tap. Refer to Figure 228. 2. Install nozzle sleeve puller J 29880 (2) to slide hammer J 2619-01 (1) or equivalent.
Insert Installation 1. Thoroughly clean insert bore and surrounding area before installing insert. 2. Apply Loctite 620 completely around the center of all three sealing diameters of the new insert. Refer to Figure 229. 3. Using nozzle sleeve installer J 29297 (2), drive insert (1) into cylinder head until it bottoms in lower counterbore face. 229
3. Thread sleeve puller into end of injection nozzle holder insert. Use slide hammer to remove insert. 228
Figure 229 — Injection Nozzle Holder Insert Installation 1. Insert
Figure 228 — Removing Injection Nozzle Holder Insert 1. Slide Hammer J 2619-01
Page 172
2. Sleeve Puller J 29880
2. Nozzle Sleeve Installer J 29297
