REPAIR INSTRUCTIONS Installation
163
Refer to Figure 164. Each camshaft bushing is located at set distances from the thrust washer mounting surface to the forward edge of the bushings.
Figure 163 — Camshaft Bushing Removal 1. Cylinder Block 2. Camshaft Bushing Remover/Installer Kit J 21428-01
3. Hammer 4. No. 1 Camshaft Bushing
Correct installation of each camshaft bushing is very important. If a bushing is not properly aligned with both its oil supply and oil feed passages in the cylinder block, either the camshaft bushing will fail or the components lubricated by the bushing feed will fail from inadequate lubrication. 164
Figure 164 — Camshaft and Auxiliary Shaft Bushing Locations
